Type: CRL8 Container Load Ramp
With a 3.0 metres overall length (1.5 metres of which is horizontal) this style allows easy placement and removal of the first and second line of pallets in a container. Fork pockets are provided either side of the ramp, along with flip-up front brackets. Securing chains both side prevent unintentional disengagement of the ramp from the container.
規格
模型 | 尺寸 Long x Wide x High (ground to ramp deck) | 容量 SWL (KG) | 單位重量 (KG) | 表面處理 |
CRL8 | 3000*2320*160 | 8000 | 600 | Enamel Paint Finish |
快速詳情
產地：中國福建（大陸）
品牌名稱：華邁
Model Number:CRL8
Product Name: Shipping container ramp
Type: CRL8
Size( Long x Wide x High): 3000*2320*160
SWL (kg): 8000kg
Unit Weight (kg): 600kg
Load Centre (mm): 1400mm
介紹]
HUAMAI container ramp is designed to allow your forklift access into standard shipping containers from ground level, as well as be used for vehicles loading from a raised dock. We typically supplied in 6500Kg or 1000Kg capacities to suit your operations, though others are available on request.
HUAMAI container ramps are greatly appreciated in the markets based on the high quality and reliable performance.
特徵：
*自動調平唇可折疊，以便您可以更方便地移動或存放容器坡道。
*當在略微不平的地面上時，它允許滿載容量。
*集裝箱坡道的後部由鋼加強，以確保在額定工作載荷下使用時的安全性。
*集裝箱坡道可以通過托盤搬運車或叉車移動通過孔。
*此斜坡的邊緣位於容器中，並通過鎖定腿固定到位。
