No-arm clamps are a type of forklift attachment that are used for handling and transporting heavy loads. These clamps attach to the forklift and allow for the safe and efficient handling of loads that are too heavy or awkward to be handled with a standard forklift. No-arm clamps are commonly used for handling paper rolls, coils, and other cylindrical loads.
No-arm clamps work by clamping onto the load with hydraulic arms. The hydraulic system is controlled by the operator, who can adjust the clamping pressure to ensure that the load is securely held in place. Once the load is clamped, the forklift can transport it to its desired location.
One of the main advantages of no-arm clamps is that they allow for the handling of loads without the need for pallets or other packaging materials. This not only saves time and money, but also reduces waste and the need for additional handling equipment.
No-arm clamps are also versatile, as they can be adjusted to handle different sizes and weights of loads. They can also be easily attached and detached from the forklift, making them convenient for use in different material handling scenarios.
In conclusion, no-arm clamps are a useful forklift attachment for handling heavy and awkward loads. They are versatile, efficient, and cost-effective, and are an essential tool for companies that handle large and heavy loads on a regular basis.
產品規格
無臂夾具
用戶可根據您的特殊需求製作專用夾臂。
適用於有特殊要求的行業
無臂夾具
功能與應用
無臂夾具是一種夾緊裝置，沒有夾臂，只有夾臂底座。用戶可根據您的特殊需要製作專用夾臂，只需將其焊接在無臂夾上即可使用。適用於對搬運和堆垛操作有特殊要求的行業。
特徵
*經過驗證的耐用T型梁臂鋁框架結構
*優越的臂滑軸承，延長使用壽命。
*再生液壓閥門，以獲得最佳的手臂速度
*出色的駕駛員視野。
選項
*提供各種安裝等級
*定制開放範圍
安裝等級：請聯繫我們獲取項目選擇和方向！
影片
| 名稱 | Capacity @ Load Center | 編號。 | 安裝類 | 開放範圍 （毫米） | 重量 （公斤） | Arm Pad Sizse （毫米） |
| 無臂夾 | Sideshifting | |||||
| 1600@600 | CNS20D-002A | II | 410-1660 | 232 | 130x565x40 | |
| 2300@600 | CNS30D-003A | II | 465-1810 | 320 | 130x625x45 | |
| 2300@600 | CNS30D-003B | III | 465-1810 | 338 | 130x625x45 | |
| 循環 | ||||||
| 1600@600 | CNR20D-004A | II | 410-1655 | 454 | 127x565x40 | |
| 2300@600 | CNR30D-005A | II | 465-1810 | 536 | 125x625x45 | |
| 2300@600 | CNR30D-005B | III | 465-1810 | 554 | 125x65x45 | |
快速詳情
產地：中國福建（大陸）
品牌名稱：華邁
型號：CNS
材料：鋼和鑄件
安裝等級：2A / 3A
證書：ISO9001：2000
